Description
Blue Sea Circuit Breaker Panel DC Branch Traditional Metal - 100A, 3 Positions
Distribute current from a high amperage input into lower amperage circuits
- All positive, negative and grounding buses installed, fully pre-wired
- Panels with meters include toggle switch for mounting up to 3 battery banks
- All panels with analog meters are owner upgradable to 24 Volts with 8240 or 8243 (18-32V DC meters)
- All circuit label positions are backlit on standard panels - No kit required
- "ON" indicating LEDs installed in all circuit positions
Note: **Panels with Push Button Circuit Breakers do not include ON-indicating LEDs or backlit label positions
| Positions | 3 |
| Circuit Breaker | 3 A-Series, 15A |
| Nominal Voltage | 12V DC 24V DC |
| Maximum Amperage | 100A |
| Height | 3.75in (95.25 mm) |
| Width | 5.25in (133.35 mm) |
| Depth | 63.5mm |
| Weight | 1.15lb (0.52 kg) |
| Included | |
|---|---|
| Qty | Product |
| 3 | A-Series White Toggle Circuit Breaker - Single Pole 15A |
| 1 | Basic DC Panel Label Set - 30 Labels [LABEL] |
