Raymarine CP570C 4KW Professional CHIRP Sonar Module

High-Performance Sonar Module For Professional & Tournament Fishing

Engineered for serious anglers, the CP570 sonar module bring best-in-class target separation and high resolution CHIRP sonar imagery to Raymarine multifunction displays. Using a wide spectrum of frequencies and greater sensitivity the CP570's advanced CHIRP transceiver can see through dense schools of baitfish, identify thermoclines, and simultaneously target desired game fish.

Rated for offshore use and rough conditions, the CP570 intelligently filters out unwanted noise while producing high resolution fish targets and reliable bottom tracking.

For the professional angler the CP570s two fully independent sonar channels deliver faster target identification and up to 4kW of combined output power.

Specifications:
Recommended for: Professional and tournement fishing
Sonar Type: Wide Spectrum CHIRP
Power: Max 4kW output using 2 independent CHIRP channels
Frequency & Channels: Dual independent CHIRP channels from 25 to 250kHz
Depth Range: 10,000ft (3,000m)

Features:
- TruZoom: provides magnified views of fish targets, bottom structure, and baitfish without loss of resolution as seen by traditional sonar.
- Automatic transducer identification with Aimar Xducer ID
- Airmar Wide Beam transducer compatible
- Waterproofing Standard: IPX6 waterproof rugged aluminum enclosure
- Compatability: aSeries, cSeries, eSeries, eS Series, gS Series
- Supply Voltage: 12/24V DC
- Power Consumption: 30. 6W (Maximum)
- Connections: Power connection, Network connection (RayNet connector) 10/100MB/s, transducer connection
