Viper Pro Series Universal 3 Piece Rocket Launcher - Small

Viper Pro Series Universal 3 Piece Rocket Launcher - Small 20008

Bell Marines roots are in manufacturing rocket launchers, bow rails, etc for many of the boat builders in Australia.

These three piece rocket launchers are fully welded, finished and hand polished to a mirror finish.

The 3 piece was developed because of the age old problem that one piece rocket launchers eventually crack at the stress points such as the top bends and where the chimneys attach etc.

They are supplied with M8 eye bolts so you can fold down your rocket launcher when required and are pre-drilled for internal wiring.

Ships worldwide in a convenient box.

P L E A S E N O T E:  Rocket Launcher (V I P-20008) will fit boats with a windscreen width of between 1600mm and 1800mm where the windscreen meets the deck (rear)

P L E A S E N O T E:  Rocket Launcher (V I P-20015) will fit boats with a windscreen width of between 1800mm and 2000mm where the windscreen meets the deck (rear)

P L E A S E N O T E: **Rocket Launcher (V I P-20016) will fit boats with a windscreen width of between 2000mm and 2200mm where the windscreen meets the deck (rear).

Note: **Pre-drilled for internal wiring for that custom look Includes: 5 Mounting brackets for accessories such as flood lights, radio aerials, G P S aerial, etc.

Constructed from 25mm 316 marine grade stainless steel tube6 Chimneys with rolled bottoms, gimble pins and plastic tops to protect your rods.

Rear grab rails for passenger comfort and safety. M8 eye bolts to collapse your rocket launcher for storage.

Bimini mounting rail built-in. Feet, tube ends and fixing hardware supplied.

Part Number Width Top Width Between Bends Height (Head Clearance to Deck)

V I P-200081700 - 1800mm1500mm1260mm

V I P-200151900 - 2000mm1700mm1260mm

V I P-200162100 - 2200mm1900mm1260mm
